Where it is used
Shown above: a powered sofa
A linear actuator turns electrical energy straight into linear motion. The mechanism is a motor, gears, a screw and nut, a guide, a rod, a carriage, a spring, a housing, a worm gear and limit switches.
Shown above: a height-adjustable desk
Together with a switch-mode supply, a controller or a panel, it becomes the adjustment system. It is precise, efficient and safe, and it replaces some hydraulic and pneumatic drives.
Shown above: a medical bed
The actuator is a core part of many smart products in medical equipment, home furniture, office furniture and industrial machines.
Power stage
Recommended parts
| Part | VRRM (V) | IF (A) | Package |
|---|---|---|---|
| MBR10200FCT | 200 | 10 | ITO-220AB |
| MBR20200FCT | 200 | 20 | ITO-220AB |
| MBR20U100CT | 100 | 20 | TO-220AB |
| MBR20200CT | 200 | 20 | TO-220AB |
| MBR20300CT | 300 | 20 | TO-220AB |
| EBR20LH200CT | 200 | 20 | TO-220AB |
| EBR30LH200CT | 200 | 30 | TO-220AB |
| SF2003 | 300 | 20 | TO-220AB |
| SF2004 | 400 | 20 | TO-220AB |
| SF2003CD | 400 | 20 | TO-263-2L |
| SF2004CD | 400 | 20 | TO-263-2L |
| SFT16H02 | 200 | 16 | TO-220AB |
Samples and selection
Request datasheets or catalog samples via the sample / inquiry channel. Browse the product catalog or cross-reference tool.
