650 V FRD selection notes

650 V fast-recovery diode catalog
Part	Package	VRRM (V)	IFAV (A)	IFSM (A)	IF (A)	VF max (V)	IR max (µA)	trr max (ns)	TJ max (°C)
SF865A	TO-220AC-A	650	8	80	8	1.8	10	35	175
SF1565A	TO-220AC-A	650	15	120	15	1.9	10	35	175
SF2065A	TO-220AC-A	650	20	150	20	2	10	40	175
SF3065A	TO-220AC-A	650	30	300	30	1.8	10	55	175
SF865ACD	TO-263-2L	650	8	80	8	1.8	10	35	175
SF1565ACD	TO-263-2L	650	15	120	15	1.9	10	35	175
SF2065ACD	TO-263-2L	650	20	150	20	2	10	40	175
SF3065ACD	TO-263-2L	650	30	300	30	1.8	10	55	175
SFF865A	ITO-220AC	650	8	80	8	1.8	10	35	175
SFF1565A	ITO-220AC	650	15	120	15	1.9	10	35	175
SFF2065A	ITO-220AC	650	20	150	20	2	10	40	175
SF865ACS	TO-252-2L	650	8	80	8	1.8	10	35	175
SFP3065A	TO-247AC-A	650	30	300	30	1.8	10	55	175
SFP30H65A	TO-247AC-A	650	30	320	30	2.4	10	40	175
SFP4065A	TO-247AC-A	650	40	450	40	1.8	10	50	175
SFP5065A	TO-247AC-A	650	50	400	50	1.8	10	80	175
SFP6065A	TO-247AC-A	650	60	500	60	1.7	10	80	175
SFP60H65A	TO-247AC-A	650	60	500	60	2.2	10	50	175
SFP7565A	TO-247AC-A	650	75	500	75	1.8	10	85	175
SFP75H65A	TO-247AC-A	650	75	500	75	2.75	10	50	175
SFP8065	TO-247AB	650	80	450	40	1.8	10	50	175
SFPD100H65	TO-247AB	650	100	500	50	1.9	10	50	175
SFP100H65A	TO-247AC-A	650	100	500	100	2.5	10	70	175
SFPD120H65	TO-247AB	650	120	500	60	2.2	10	50	175

Product Series: 650 V Fast-Recovery Diodes

The figures above list packages, voltage and current ratings, and the operating points recommended for this series.

Product Series: 650 V Fast-Recovery Diodes

Samples and selection

Request datasheets or catalog samples via the sample / inquiry channel. Browse the product catalog or cross-reference tool.
